Image to CAD DXF

Create DXF from Image

Clark Custom Kitting image for 5S tool and component control. Eliminates the time exhaustive process of tracing, measuring or even shipping out tools and components to ensure a custom fit for your tool organizer.

With Clark Foam Image to DXF generator, create a catalog of accurate dxf files in minutes. Instantly capture precise cad files to create custom tool and component kit that can be updated and redesigned quickly and accurately.

No matter how difficult or intricate the tool or component might be, you can be confident in achieving an exact drawing. Create hundreds of complete CAD files for a variety of objects in minutes instead of days.

beforeafter

3 Easy Steps

SET UP THE BACKLIGHT

Prior to taking images of tools or components, the LED backlight must be setup. It is best to place the LED backlight as low as possible. This allows for a greater field of view.

ACQUIRING AN IMAGE

Once the tools/components are in place on the LED backlight an image can be captured. Hold the camera above the backlight so that it is perpendicular to the tool.

IMAGE PROCESS TO DXF

Email or upload your images to Clark Custom Kitting for image processing and tool liner layout

focus on what’s important, simple, innovative

Creating Solutions :: Custom Tool Kitting Made Easy

How it Works

Tool Control is not Difficult We make it Easy!

The Image To DXF Generator allows the user to capture images of tools or components against a LED backlight using a camera phone or digital camera.
After images have been captured, the images can  be uploaded to the DXF Generator to create DXF files. These files are then used to create
custom foam kits. See the video

• Fast
• Efficient
• Cost Effective
• Time Efficient
• Simple – 2 Step Process
• At your Location
